0.9 BDL3245E/BDL4245E/BDL4645E
32”/42”/46” FHD LCD PUBLIC DISPLAY
2011-07-01 PHILIPS Page 9 of 38
MMD Con
idential
2.4 Service mode
Detailed technical specification refers to Service delta technical specs.
• Software Update:
¾ Through RS-232, RJ-45 and USB
The system should have the recovery mechanism when updating failure
2.5 Power Supply
2.5.1 Power supply features
• AC line voltage range - 90Vac ~ 264Vac.
• AC line frequency range - 50-60 Hz ± 3 Hz.
• DC tact switch - Minimal power consumption when switch off
• AC mains switch - No power consumption when switch off.
• Inrush current - < 40A at 240Vac when cold start.
• Leakage current - < 0.5mA at 240Vac.
• Power factor correction - According to EN61000-3-2
2.5.2 Power consumption
• Normal on - 32” 140W (typical), 160W(max.)
• 42” 210W (typical), 260W(max.)
• 46” 220W (typical), 270W(max.)
When Lan turn off power consumption spec:
• Power saving (LAN off) - < 1W
• Power saving (schedule ON) < 2W
• Power saving < 2W
• Switch off (DC off) or standby - < 0.5W,remote off
• Switch off (AC mains) - < No power consumption.
• Recovery times 15sec for change mode and power start time.
When Lan turn on power consumption spec:
• Power saving < 5W
• DC OFF < 3W (Lan ON Status)
• Recovery times 15sec for change mode and power start time.
For OPS module
OPS module no need to judge thermal temperature just qualification for functionality
2.5.3 Display DPM standby
z DPM - The Display enters DPM off (sleep) mode when no H&V sync, one of H-
sync / V-sync input or digital clock is absent. “No Signal” message appears before
entering DPM mode.
And then, show “
Going to Deep Sleep”
message for 3
seconds. A delay of 3 seconds before entering the power saving state is
required to avoid misunderstanding of display resolution and timing mode
changes.
