0.9 BDL3245E/BDL4245E/BDL4645E
32”/42”/46” FHD LCD PUBLIC DISPLAY
2011-07-01 PHILIPS Page 28 of 38
MMD Con
idential
6.6 Others
Logo nameplate
Saddle
Main Switch Cover
7. MECHANICAL
7.1 Cosmetic
Philips ID -
7.2 Mechanical Data Files
Provide mechanical drawings with key dimensions.
7.3 Location of Philips Logo
7.4 Location of Icons
7.5 Color for Resin / Paint
Black 30% gloss front/Silver brush gloss decoration part/Stealth Black in mould back-cover.
7.6 Resins
• RoHS requirements.
• WEEE requirements.
• PC+ABS
• China Rohs required. (sales in China only)
7.7 Paint Used
• RoHS requirements.
• WEEE requirements.
7.8 Plastic Mold Tooling
• Tooling to be designed to minimize cosmetic defects induced by molding process (sink,
blush, weld lines, gate marks, ejector marks, etc.).
• Painting to cover up cosmetic defects due to molding is strongly discouraged.
No plastic mold tooling
