0.9 BDL3245E/BDL4245E/BDL4645E
32”/42”/46” FHD LCD PUBLIC DISPLAY
2011-07-01 PHILIPS Page 29 of 38
MMD Con
idential
7.9 Plastics Flammability
• All Plastics to be Flame Retardant UL 94-V0 or Better (if Display weighs less than 18kg;
UL94-V0 is OK).
• Base / Pedestal to be Flame Retardant UL 94-HB.
• All major plastic parts (bezel, back cover, base) need to be molded from same resin. Base /
Pedestal otherwise specified.
7.10 Texture/Glossing of Housing
• The texture area and texture no should follow Philips make-up sheet.
• The exterior surfaces shall have a uniform texture.
• Philips must approve the mold texturing.
• Detail document for texture refer to UN-D249.
• The gloss value of texture area < = 20 gloss units.
7.11 Base Tilt / Swivel Range
• Tilt - N.A. (per commercial spec request)
• Swivel Range - 0°
• Base detach - Should be directly disassembled from main body, so as for easy
install the Display to wall mount.
• Tip over - 15° minimum in worst case, base dimension designed so that ID
and tip over requirements can be met.
7.12 Movement of Unit with Base
• Base must have non-marring, non-staining feet.
• Unit must tilt up and down with no “Stick / Slip”.
• Base must provide sufficient friction to hold unit in desired position after adjusting tilt.
7.13 Wall Mount Method
• VESA in back-cover.
7.14 Label
• Regulatory label / Carton label should follow Philips requirement.
• Detail document refer to Philips Engineering Reference Book.
