36
Power Board
BDL3245E
BDL4245E &BDL4645E
EMI Filter
PFC Converter
R2A20117CSP
AC Input
Bridge Rectifier
D15XB60
AUX Converter
A6069H
Main Power
SSC9512S
PS_ON
+24V
To Backlight and
audio am
p
lifier
+12V
To LV D S
+5V
To MCU and
Scaler Board
Vcc
EMI Filter
PFC Converter
ICE2PCS02H
AC Input
Bridge Rectifier
D15XB80
AUX Converter
A6069H
Main Power
L6599DTR
PS_ON
+24V
To Backlight and
audio am
p
lifier
+12V
To LV D S
+5V
To MCU and
Scaler Board
Vcc
