Watchdog 257 May 03, 2004

Philips Semiconductors Preliminary User Manual

LPC2119/2129/2194/2292/2294ARM-based Microcontroller

The Watchdog contains 4 registers as shown in Table 193 below.

*Reset Value refers to the data stored in used bits only. It does not include reserved bits content.

Table 193: Watchdog Register Map

Name Description Access

Reset

Value*

Address

WDMOD

Watchdog mode register. This register contains the basic mode and

status of the Watchdog Timer.

Read/Set 0 0xE0000000

WDTC

Watchdog timer constant register. This register determines the time-out

value.

Read/Write 0xFF 0xE0000004

WDFEED

Watchdog feed sequence register. Writing AAh followed by 55h to this

Write Only NA 0xE0000008

WDTV

Watchdog timer value register. This register reads out the current value

of the Watchdog timer.

Read Only 0xFF 0xE000000C
