REGISTER DESCRIPTION
The VIC implements the registers shown in Table 40. More detailed descriptions follow.
Table 40: VIC Register Map
Name Description Access
Reset
Value*
Address
VICIRQStatus
IRQ Status Register. This register reads out the state of those interrupt
requests that are enabled and classified as IRQ.
RO 0 0xFFFF F000
VICFIQStatus
FIQ Status Requests. This register reads out the state of those interrupt
requests that are enabled and classified as FIQ.
RO 0 0xFFFF F004
VICRawIntr
Raw Interrupt Status Register. This register reads out the state of the 32
interrupt requests / software interrupts, regardless of enabling or
classification.
RO 0 0xFFFF F008
VICIntSelect
Interrupt Select Register. This register classifies each of the 32 interrupt
requests as contributing to FIQ or IRQ.
R/W 0 0xFFFF F00C
VICIntEnable
Interrupt Enable Register. This register controls which of the 32 interrupt
requests and software interrupts are enabled to contribute to FIQ or
IRQ.
R/W 0 0xFFFF F010
VICIntEnClr
Interrupt Enable Clear Register. This register allows software to clear
one or more bits in the Interrupt Enable register.
W 0 0xFFFF F014
VICSoftInt
Software Interrupt Register. The contents of this register are ORed with
the 32 interrupt requests from various peripheral functions.
R/W 0 0xFFFF F018
VICSoftIntClear
Software Interrupt Clear Register. This register allows software to clear
one or more bits in the Software Interrupt register.
W 0 0xFFFF F01C
VICProtection
Protection enable register. This register allows limiting access to the VIC
registers by software running in privileged mode.
R/W 0 0xFFFF F020
VICVectAddr
Vector Address Register. When an IRQ interrupt occurs, the IRQ service
routine can read this register and jump to the value read.
R/W 0 0xFFFF F030
VICDefVectAddr
Default Vector Address Register. This register holds the address of the
Interrupt Service routine (ISR) for non-vectored IRQs.
R/W 0 0xFFFF F034
VICVectAddr0
Vector address 0 register. Vector Address Registers 0-15 hold the
addresses of the Interrupt Service routines (ISRs) for the 16 vectored
IRQ slots.
R/W 0 0xFFFF F100
VICVectAddr1 Vector address 1 register R/W 0 0xFFFF F104
VICVectAddr2 Vector address 2 register R/W 0 0xFFFF F108
VICVectAddr3 Vector address 3 register R/W 0 0xFFFF F10C
VICVectAddr4 Vector address 4 register R/W 0 0xFFFF F110
VICVectAddr5 Vector address 5 register R/W 0 0xFFFF F114
VICVectAddr6 Vector address 6 register R/W 0 0xFFFF F118
VICVectAddr7 Vector address 7 register R/W 0 0xFFFF F11C
VICVectAddr8 Vector address 8 register R/W 0 0xFFFF F120
VICVectAddr9 Vector address 9 register R/W 0 0xFFFF F124
