FL MGUARD RS2000 TX/TX-B
112
PHOENIX CONTACT 105656_en_05
5.6.2 Performing a recovery procedure
Objective (up to 8.3.x) Up to mGuard firmware version 8.3.x
The network configuration (but not the rest of the configuration) is to be reset to the de-
livery state, as it is no longer possible to access the device.
When performing the recovery procedure, the default network settings are established:
The device is reset to Router mode with the default settings.
– In addition, MAU management is switched on for Ethernet connections. HTTPS access
is enabled via the local Ethernet connection (LAN).
Possible reasons for performing the recovery procedure:
– The configured IP address of the device differs from the default setting.
– The current IP address of the device is not known.
Objective (8.4.0 or later) mGuard firmware version 8.4.0 or later
The complete configuration (and not only the network configuration) is to be reset to the
delivery state, as it is no longer possible to access the device.
The current configuration will be automatically be saved on the device and can be restored
after the recovery procedure is finished.
When performing the recovery procedure, the default network settings are established:
Activity during the recovery procedure (mGuard firmware version 8.4.0 or later)
Before performing the recovery procedure, the current configuration of the device is stored
in a newly generated configuration profile ( "Recovery-DATE"). After the recovery proce-
dure has finished, the device starts with the Factory Default settings.
The configuration profile named "Recovery DATE" subsequently appears in the list of con-
figuration profiles and can be edited and restored with or without changes.
Action • Slowly press the Reset button six times.
After approximately 2 seconds, the STAT LED lights up green.
• Press the Reset button slowly again six times.
If successful, the STAT LED lights up green.
If unsuccessful, the ERR LED lights up red.
If successful, the device restarts after two seconds and switches to Stealth mode. The de-
vice can then be reached again under the corresponding addresses.
Table 5-4 Preset addresses
Default setting Network mode Management IP #1 (IP
address of the internal
interface)
FL MGUARD RS2000 TX/TX-B Router https://192.168.1.1/
Table 5-5 Preset addresses
Default setting Network mode Management IP #1 (IP
address of the internal
interface)
FL MGUARD RS2000 TX/TX-B Router https://192.168.1.1/
