third slope of the response curve.
By default, the third slope is not used, so the default value is
0.
Set the ADC calibration mode:
0 No calibration
1 Calibration during overhead row
2 Calibration at start of each (conversion) row
(60 fps mode only!)
3 Calibration during overhead row and at start of each
(conversion) row (60 fps mode only!)
Set the column amplifier calibration mode:
0 No calibration
1 Calibration at start of each row
Select the (input) high speed clock:
0 LVDS input clock
1 Analog PLL
2 & 3 Digital PLL
Change the behavior of the row select:
0 Select constant high during sampling
1 Select is low during transfer
Set the behavior of the ADC clock
0 ADC clock stops between reset and signal
conversion
1 ADC clock continues to toggle between reset and
signal conversion
Controls behavior of electrical black columns
0 All columns normal
1 First 20 columns (in non-flipped readout) are black, rest
are normal
Disable/Enable digital test image output
Change the handling of large conversion results
0 Output is clipped at ‘1111111111’
1 Output overflows and outputs lowest 10 bits
Change the clock edge that is used to sample the
digital data when going from parallel to serial data
0 Read out left bottom to right top
1 Read out right bottom to left top
2 Read out left top to right bottom
3 Read out right top to left bottom
Set the training word that is sent on the data
channels when the sensor is idle
Select output signal on digital multiplexer 1:
0 clk_pix
1 slot_adc
2 fval
