PHOTONIS | 24
NVT 200-LC-0103
Revision: D
Page 24 of 43
Name
Address
Size
Description
3  dval
4  sync_x_even
5  sync_x_odd
6  line_0_sample
7  line_0_adc
8  line_0_read
9  adc_ramp_r
10  adc_ramp_s
11  adc_vtzero
12  col_init
13  col_init_off
14  pix_select
15  pix_transfer
TMUX2
27
4
Select output signal on digital multiplexer 2:
0  clk_adc_gated
1  slot_pix
2  lval
3  bypass_even
4  sensor_idle
5  reset_first
6  reset_second
7  reset_third
8  row_clk_y
9  row_sync_y_read
10  row_sync_y_inte0
11  row_sync_y_inte1
12  row_sync_y_inte2
13  write
14  read
15  col_vtzero
DPLL_MULT
30
8
Digital PLL multiplication factor (252 = x10)
DPLL_EN
31
1
Disable/Enable digital PLL
DPLL_DIVMODE
31
1
Internal selection of feedback mechanism in digital
PLL
DPLL_F_RANGE
31
2
Select output frequency range of digital PLL
APLL_MULT
32
5
Analog PLL multiplication factor = APLL_MULT + 1
TMUXA
33
4
Select output signal on analog multiplexer:
0  ground
1  CMDN_LVDS_REC
2  CMDN_2X
3  REF144
4  REF270
5  VDCPC_ADC
6  VCLAMP_ADC
7  VBGAP_BIAS
8  VTSIG
9  VTREF
10  VREF
11  VRAMP
