Name Torque in Nm
Upper shock absorber retainer 40 ÷ 45
FRONT BRAKE
Name Torque in Nm
Brake fluid pump-hose fitting 16 ÷ 20
Oil bleed screw 12 - 16
Pad fixing pin 19.6 ÷ 24.5
Screw tightening calliper to support 24 ÷ 27
Brake disc screws 8 to 10
Brake fluid pipe-calliper fitting 20 to 25
REAR BRAKE
Name Torque in Nm
Rear brake calliper-pipe fitting 20 to 25
Rigid / flexible pipe fitting 13 - 18
Rear brake pump-pipe fitting 16 - 20
Rear brake calliper fixing screws 20 to 25
Brake disc screws 8 to 10
Pad fixing pin 19.6 ÷ 24.5
MUFFLER
Name Torque in Nm
Silencer heat guard fixing screw 4 to 5
Screw for fixing silencer to supporting arm 20 to 25
Lambda probe tightening on exhaust manifold 40 to 50
Exhaust manifold-silencer joint tightening 12-13
Nut fixing silencer to cylinder head 16 to 18
LUBRICATION
Name
Torque in Nm
Hub oil drainage plug 15 to 17
Oil filter on crankcase fitting 27 to 33
Engine oil drainage plug/ mesh filter 24 to 30
Oil filter 4 to 6
Oil pump cover screws 7 - 9
Screws fixing oil pump to the crankcase 5 to 6
Oil pump command sprocket screw 10 to 14
Oil pump cover plate screws 4 to 6
Oil sump screws 10 to 14
Minimum oil pressure sensor 12 to 14
CYLINDER HEAD
Name
Torque in Nm
Spark plug 12 to 14
Head cover screws 6 - 7
Nuts fixing head to cylinder 7±1 + 10±1 + 270°
Head fixing side screws 11 - 12
Starter ground screw 7 to 8.5
Tappet adjustment check nut 6 - 8
Intake manifold screws 11 to 13
Timing chain tensioner slider screw 10 to 14
Starter counterweight support screw 11 to 15
Timing chain tensioner support screw 11 to 13
Timing chain tensioner central screw 5 to 6
Camshaft retention plate screw 4 to 6
TRANSMISSION
Name
Torque in Nm
Belt support roller screw 11 to 13
Clutch unit nut on driven pulley 45 to 50
Drive pulley nut 75 to 83
Transmission cover screws 11 to 13
Characteristics Beverly Tourer 300 i.e.
CHAR - 12
