Refitting the driven pulley
- Insert the new oil seals and O-rings on the mov-
able half-pulley.
- Lightly grease the O-rings «A» shown in the fig-
ure.
- Fit the half-pulley over the bushing using the spe-
cific tool.
- Check that the pins are not worn and proceed to
refitting them in their slots.
- Refit the torque server closure collar.
- Using a curved-spout grease gun, lubricate the
driven pulley unit with approximately 6 grams of
grease. Apply grease through one of the holes in
the bushing until it comes out through the hole on
the opposite side. This operation is necessary to
avoid the presence of grease beyond the O-rings.
N.B.
THE TORQUE SERVER CAN BE GREASED WHETHER
WITH BEARINGS FITTED OR WHEN THEY ARE BEING RE-
PLACED; UNDERTAKING THE OPERATION WHEN THE
BEARINGS ARE BEING SERVICED MIGHT BE EASIER.
Specific tooling
020263Y Driven pulley assembly sheath
Recommended products
AGIP GREASE SM 2 Grease for the C-ring of
the tone wheel
Soap-based lithium grease containing NLGI 2 Mo-
lybdenum disulphide; ISO-L-XBCHB2, DIN
KF2K-20
Engine Beverly Tourer 300 i.e.
ENG - 124
