PIAGGIO Beverly Tourer 300 i.e. - Crankcase and Crankshaft

Name Torque in Nm
Driven pulley shaft nut 54 to 60
Rear hub cap screws 24 to 27
FLYWHEEL
Name Torque in Nm
Flywheel cover screw 11 to 13
Stator assembly screws 3 - 4 (Apply LOCTITE medium type 242 threadlock)
Flywheel nut 94 - 102
Pickup fixing screws 3 to 4
Screw fixing freewheel to flywheel 13 - 15
CRANKCASE AND CRANKSHAFT
Name Torque in Nm
Internal engine crankcase bulkhead (transmission-side half
shaft) screws
4 to 6
Engine-crankcase coupling screws 11 to 13
Starter screws 11 to 13
Crankcase timing cover screws 3.5 - 4.5 (Apply LOCTITE medium type 242 threadlock)
COOLING
Name Torque in Nm
Water pump rotor cover 3 ÷ 4
Screws for water pump rotor driving link 3 ÷ 4
Thermostat cover screws 3 ÷ 4
bleed screw: 3
Overhaul data
Assembly clearances
Cylinder - piston assy.
Beverly Tourer 300 i.e. Characteristics
CHAR - 13
