PIAGGIO Beverly Tourer 300 i.e. User Manual

Dimensions and mass
WEIGHTS AND DIMENSIONS
Specification
Desc./Quantity
Length 2110 mm
Width to handlebar 770 mm
Wheelbase 1470 mm
Height 1500 mm
Kerb weight 165 kg ± 5 kg
Maximum weight allowed 350 kg
Engine
ENGINE
Specification
Desc./Quantity
Type Single-cylinder, 4-stroke
Engine capacity 278 cm³
Bore x Stroke 75x63 mm
Compression ratio 11 ± 0.5 : 1
Engine idle speed 1,700 ± 100 rpm
Timing system 4 valves, single overhead camshaft, chain-driven.
Valve clearance Intake: 0.10 mm Exhaust: 0.15 mm
Max. power 16.1 kW at 7,250 rpm
MAX. torque 23 Nm at 6,000 rpm
Lubrication Engine lubrication with lobe pump (inside crankcase), chain-
driven, with double filter: mesh and paper.
Lubrication pressure 4 bar
Minimum lubrication pressure (100° C) 0.8 bar
Beverly Tourer 300 i.e. Characteristics
CHAR - 9
