Electrode gap
0.7 to 0.8 mm
Locking torques (N*m)
Spark plug 12 to 14
Hub oil
Check
-Place the vehicle on the centre stand on flat
ground;
- Remove the oil dipstick «A», dry it with a clean
cloth and put it back into its hole tightening it
completely;
Remove the dipstick and check that the oil level is
slightly over the second notch starting from the
lower end; if the level is under the MAX. mark, it
needs to be filled with the right amount of hub oil.
-Screw up the oil dipstick again and make sure it
is locked properly into place.
Replacement
-Remove the oil filler cap «A».
- Unscrew the oil drainage cap «B» and drain out
all the oil.
- Screw in the drainage cap again and fill the hub
with the prescribed oil.
Recommended products
AGIP ROTRA 80W-90 Rear hub oil
SAE 80W/90 Oil that exceeds the requirements of
API GL3 specifications
Characteristic
Rear hub oil
Maintenance Beverly Tourer 300 i.e.
MAIN - 44
