17. Stand switch: remove the left footrest to reach
it.
18. Saddle opening actuator: remove the left side
panel to reach it.
19. Injection ECU: remove the inspection cover lo-
cated in the helmet compartment to reach it.
20. Plug socket: located in the helmet compart-
ment.
Electrical system Beverly Tourer 300 i.e.
ELE SYS - 70
