51. pre-installation for anti-theft device
54. auxiliary fuses unit: fuses 8,9,10
Lights and turn indicators
1.
bulbs for turn indicator warning lights
2. turn indicator bulbs
3. turn indicator switch
4. turn indicator control device
26. stop light bulb
27. helmet compartment light bulb
28. helmet compartment light control switch
29. battery
30. main fuses unit: fuses 1,3,5
44. light switch
45. instrument panel lighting bulbs
46. front tail light bulb
47. tail light bulb
48. license plate light bulb
49. key switch contacts
50. headlight with twin-filament bulb
Electrical system Beverly Tourer 300 i.e.
ELE SYS - 82
