Capacities
CAPACITY
Specification Desc./Quantity
Rear hub 150 cm³
Cooling system ~ 1.2 l
Engine oil ~ 1000 cm³
Fuel tank (including a ~ 2.5 l reserve) ~ 14.5 l
Electrical system
ELECTRICAL COMPONENTS
Specification Desc./Quantity
Generator Three-phase alternating current
Battery 12V -10 Ah
Ignition type Electronic capacitive discharge ignition (CDI) and variable ad-
vance, with separate HV coil.
Frame and suspensions
CHASSIS AND SUSPENSIONS
Specification
Desc./Quantity
Rear wheel max. travel 90 mm.
Rear suspension Engine with oscillating fork articulated to the chassis by means
of a double swinging arm. Double-acting hydraulic shock ab-
sorbers, coaxial helicoidal spring with variable step, adjustable
at preloading on 4 positions.
Front fork stroke 90 mm
Front suspension Hydraulic telescopic fork with Ø 35-mm stem
Type of chassis Welded tubular steel chassis with stamped sheet reinforce-
ments.
Brakes
BRAKES
Specification
Desc./Quantity
Rear Ø 240 mm stainless steel disc with Brembo "Serie Oro" floating
calliper with Ø 34 mm twin plungers
Integral braking system Left lever acts on the left front and rear discs, through a valve
that distributes the pressure; the right lever acts on the right
front disc only
Front Ø 240 mm stainless steel double disc with Ø 34 mm Brembo
"Serie Oro" floating calliper (front Right) / Ø 32 (front Left)
Wheels and tyres
WHEELS AND TYRES
Specification
Desc./Quantity
Tyre pressure (when cold) Front: 2.1 bar Rear: 2.3 bar (2.5 bar with driver and luggage)
Front tyre Without inner tube: 120/70-14" 55P
Rear tyre Without inner tube: 140/60-14" 64P
Front wheel alloy rim: 14'' x 3.50
Rear wheel alloy rim: 14'' x 3.50
Characteristics X9 Evolution 125
CHAR - 10
