PIAGGIO X9 Evolution 125 2008 - Top-case Removal

Expansion tank
- Unscrew the fixing screws from the expansion
tank support and remove the support;
- Slide off the expansion tank downwards with the
relative gasket after removing momentarily the
cap;
- Prepare a container for the coolant.
- Close the cap again and remove the coolant de-
livery and reverse pipes.
Top-case
- Unscrew the fixing screws from the electrical
connection indicated in the figure;
- Remove the expansion tank as described before;
- Unscrew the screw inside the case and remove
it together with the saddle latch transmission.
X9 Evolution 125 Chassis
CHAS - 201
