Flywheel cover
- Remove the two clamps, the two couplings and
empty the cooling system.
- Remove the 4 retainers and the flywheel cover.
Removing the hub cover
- Remove the two clamps, the two couplings and
empty the cooling system.
- Remove the 4 retainers and the flywheel cover
X9 Evolution 125 Engine
ENG - 109
