Centre-stand
Removal
- Unhook the springs.
- Loosen the nut.
- Pull out the screw.
Reassembly
- Install the sealing rings on the support tube of the
stand;
- Carry out the operations described above in re-
verse order, then insert the sealing rings into their
seats.
CAUTION
Lubricate the following parts with grease: spring coupling
pins, bushings on stand fixing bracket.
Recommended products
AGIP GREASE PV2 Grease for control levers
on the engine
White anhydrous-calcium based grease to protect
roller bearings; temperature range between -20 °
C and +120 °C; NLGI 2; ISO-L-XBCIB2
Locking torques (N*m)
stand retaining bolt 20 ÷ 25
X9 Evolution 125 Suspensions
SUSP - 175
