PIAGGIO X9 Evolution 125 2008 - Tightening Torques

Specification Desc./Quantity
Stamping 303A
Tapered pin notches position from top Fixed position
Max. air jet 70
Diffuser nozzle Ø 2.8
Starter jet 42
Starter device resistance ~ 20 Ω
Diffuser Ø 29
Tapered pin stamping NDWA
Minimum mixture set screw initial opening ± ¼
Throttle valve spring 150 ÷ 250 g
Minimum air jet 115
Minimum jet 38
Max. jet 100
Starter air jet Ø 1.5 (body)
Starter diffuser nozzle Ø 1.5 (body)
N.B.
THE IDENTIFICATION LETTER CAN VARY WITH EACH CARBURETTOR UPDATE
Walbro
WALBRO CARBURETTOR
Specification Desc./Quantity
Tapered pin notches position from top 3
Tapered pin stamping 465
Minimum mixture set screw initial opening 3 ± 1/4
Throttle valve spring 120 g
Minimum air jet 50
Max. air jet 150
Minimum jet 34
Max. jet 118
Body stamping 7HO
Vacuum type WVF-7H*
Diffuser Ø 29 (30.3x27.0)
Starter jet 50
Starter diffuser jet 130
Starter air jet 200
Diffuser nozzle Ø 2.7
Stamping
N.B.
THE IDENTIFICATION LETTER CAN VARY WITH EACH CARBURETTOR UPDATE
Tightening Torques
TECHNICAL SERVICE NOTES
For correct tightening, the expansion tank cap locking torque has been standardised to 2.5 Nm
REAR BRAKE
Product
Description Specifications
(°) Loctite 243 Medium-strength threadlock Apply LOCTITE 243 medium-strength
threadlock
FRONT BRAKE
Name
Torque in Nm
Oil bleed screw 8 ÷ 12
Disc tightening screw (°) 5 ÷ 6
Brake fluid pipe-calliper fitting 16 ÷ 20
X9 Evolution 125 Characteristics
CHAR - 15
