PIAGGIO X9 Evolution 125 2008 - Air Filter and Engine Oil Maintenance

Check
- Rest the vehicle on its centre stand on an even surface. - Unscrew the oil dipstick, dry it with a clean
cloth and reinsert it, screwing it in thoroughly.- Take out the dipstick and check that the oil level reaches
the 2nd notch from the bottom.- Screw the dipstick back into place completely.
Recommended products
AGIP ROTRA 80W-90 Rear hub oil
SAE 80W/90 Oil that exceeds the requirements of API GL3 specifications
Locking torques (N*m)
Hub oil drainage plug 15 ÷ 17
Replacement
-Remove the oil cap «A».
- Unscrew the oil drainage cap "B" and drain out
all the oil.
- Screw on the drainage plug and fill up the hub
with oil (about 150 cc)
Air filter
- To clean the filtering element proceed as follows: remove the 4 filter cover fixing screws indicated in
the figure; remove the cover and take out the paper filtering element, clean with compressed air and
refit.
- Make sure the filtering element is in the correct position.
- Check that the air passage sections are not damaged or deformed.
- Check the correct sealing of the coupling between the filter housing and the cover.
N.B.
FAILURE TO OBSERVE THESE INSTRUCTIONS MAY RESULT IN WRONG VACUUM INSIDE THE
FILTER HOUSING, WHICH IN TURN MAY PRODUCE VARIATIONS IN CARBURETION.
Maintenance X9 Evolution 125
MAIN - 44
