PIAGGIO X9 Evolution 125 2008 - Front Suspension; Crankcase and Crankshaft

Name Torque in Nm
Brake fluid pump-hose fitting 16 ÷ 20
Tightening screw for calliper support to the fork 45 ÷ 55
REAR SUSPENSION
Name Torque in Nm
Upper shock absorber clamp 33 ÷ 41
Lower shock absorber clamp 33 ÷ 41
Rear wheel axle 104 ÷ 126
FRONT SUSPENSION
Name Torque in Nm
Fork leg screw 6 ÷ 7
Front wheel axle 45 ÷ 50
Fork plate screw 25 ÷ 34
CHASSIS
Name Torque in Nm
Centre stand bolt 25 ÷ 30
Frame arm-engine arm bolt 60 ÷ 64
Swinging arm buffer nut 20 ÷ 25
Frame-swinging arm bolt 66 ÷ 80
Engine-swinging arm bolt 33 ÷ 41
STEERING
Name
Torque in Nm
Upper steering ring nut 30 ÷ 36
Steering lower ring nut 10 ÷ 13 then loosen by 90°
Handlebar fixing screw (*) 45 ÷ 50
Fixing screws for the handlebar control unit U-bolts 7 ÷ 10
ENGINE - COOLING
Product
Description Specifications
(°) Loctite 243 Medium-strength threadlock Apply LOCTITE 243 medium-strength
threadlock
CRANKCASE AND CRANKSHAFT
Name
Torque in Nm
Internal engine crankcase bulkhead (transmission-side half
shaft) screws
4 ÷ 6
Engine-crankcase coupling screws 11 ÷ 13
Starter motor screws 11 ÷ 13
Crankcase timing system cover screws (°) 3.5 ÷ 4.5
ENGINE - FLYWHEEL
Name
Torque in Nm
Pick-Up clamping screws 3 ÷ 4
Stator assembly screws (°) 3 ÷ 4
Flywheel cover fixing screws 5 - 6
Flywheel nut (250) 94 ÷ 102
Screw fixing freewheel to flywheel 13 ÷ 15
ENGINE - TRANSMISSION
Name
Torque in Nm
Rear hub cover screws 24 ÷ 27
Driven pulley shaft nut 54 ÷ 60
Transmission cover screws 11 ÷ 13
Drive pulley nut 75 ÷ 83
Clutch unit nut on driven pulley 55 ÷ 60
Belt support roller screw 11 ÷ 13
Characteristics X9 Evolution 125
