PIAGGIO X9 Evolution 125 2008 - Steering Tube Bearing Adjustment

Lubricate the seats and the balls.
Lock in place and turn the wrench anticlockwise
Specific tooling
020055Y Wrench for steering tube ring nut
Recommended products
AGIP GREASE PV2 Grease for steering bear-
ings, bolt seatings for swinging arms and fay-
ing surface of driven pulley spring (only pulley
side)
Soap-based lithium and zinc oxide grease con-
taining NLGI 2; ISO-L-XBCIB2
Locking torques (N*m)
Steering bearing upper seat 1) 80 ÷ 90°. Steering
bearing upper seat 50 ÷ 60 N.m
- Tighten the lower ring nut to the prescribed tor-
que.
- Loosen the lower ring nut by 90°
- Insert the spacer
- Lock the upper ring nut to the prescribed torque.
Specific tooling
020055Y Wrench for steering tube ring nut
Locking torques (N*m)
Upper steering ring nut 30 ÷ 33 Lower steering
ring nut 12 ÷ 15
Suspensions X9 Evolution 125
SUSP - 170
