With the hot air gun, drw. No. 20151y, heat the in-
ner side of the flywheel cover .
N.B.: Avoid overheating as this may alter the
painted surface.
- Place the flywheel cover on the ring base follow-
ing the same procedure as for removal.
- Place the two bearings on the specific punch.
N.B. Always use new bearings.
- Use grease to keep the bearings on the appro-
priate tool.
- Use a plastic mallet to insert the bearings on the
housing up to the stop.
- Assembly the ceramic ring and the correspond-
ing rubber gasket. The ceramic ring chamfering
should always face towards the gasket.
- Lubricate the rubber gasket and insert the unit on
the flywheel cover.
Use the punch of the specific tool 020440Y man-
ually if necessary.
N.B. Always use new ceramic ring and gaskets.
Fitting the ceramic sealing ring other than man-
ually may damage the ring.
X9 Evolution 125 Cooling system
COOL SYS - 191
