PIAGGIO X9 Evolution 125 2008 - Thermostat Removal, Check, and Refitting

Removal
- Loosen the two screws indicated in the figure and
remove the thermostat cover.
- Remove the thermostat with its gasket.
Check
- Visually check that the thermostat is not dam-
aged.
- Prepare a metal container with approx. 1 litre of
water.
- Immerse the thermostat, keeping it in the centre
of the container.
- Immerse the multimeter temperature probe, near
the thermostat.
- Warm up the container using the heat gun.
- Check the temperature when the thermostat
starts to open:
- Heat up until the thermostat is completely open
X9 Evolution 125 Cooling system
COOL SYS - 195
