Refitting
- Place the thermostat with the bleeding hole at the
highest point.
- Make sure that the rubber gasket is positioned
properly.
- Fit the thermostat cover with the connection for
the carburettor heating pipe facing the flywheel.
- Tighten the two screw to the torque indicated be-
low.
Locking torques (N*m)
Thermostat cover screws 3 ÷ 4
X9 Evolution 125 Cooling system
COOL SYS - 197
