Frame
CHASSIS REPAIR TIME
Code
Action Duration
1 004148 footboard support bracket two sides
- Replacement
2 004147 Footrest support bracket, one side -
Replacement
3 004116 Rear frame - Replacement
4 004146 Front frame - Replacement
5 004001 Frame - replace
X9 Evolution 125 Time
TIME - 223
