PIAGGIO X9 Evolution 125 2008 - Instrument Panel and Wiring Diagrams

41. Digital instrument panel
A. Preset warning light
B. ABS wiring warning light
C. Stop light bulb burned warning light
D. Disabled engine warning light
E. Oil warning light
F. Low fuel warning light
G. Headlight warning light
H. High-beam warning light
I. Left turn indicator warning light
L. Emergency flashing warning light
M. Right turn indicator warning light
42. Analogue instrument panel
A. Immobilizer warning light
B. Instrument panel bulb
43. Emergency flashing button
44. Turn indicator switch
45. Wiring for control unit power
46. External temperature sensor
47. Thermoswitch
48. Electric fan
49. Key switch
50. Side stand button
51. Automatic starter
52. Saddle opening actuator
53. Saddle opening switch
54. Fuel pump
55. Wiring for radio display
56. Control unit display wiring
57. Electric pump control device
58. Spark plug
59. HV coil
KEY
Ar: Orange Az: Sky Blue Bi: White Bl: Blue Gi: Yellow Gr: Grey Ma: Brown Ne: Black Ro: Pink Rs:
Red Ve: Green Vi: Purple
X9 Evolution 125 Electrical system
