Install the base unit
Operating Manual PITreader, PITreader Firmware V1.5.x
1004806-EN-08
| 33
6.2 Dimensions in mm
31.752
22
72.3
49.5
70.6
22.3
43.954
9.417
28.589
22.464
44.6
