Technical details
Operating Manual PITreader, PITreader Firmware V1.5.x
1004806-EN-08
| 51
11 Technical details
General
Certifications CE, FCC, IC, cULus Listed
Sensor's mode of operation Transponder
Transponder
Energy supply to transponder passive (battery free)
Frequency band 13,24 - 13,88 MHz
Max. transmitter output 170 mW
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Type of power supply SELV/PELV
Voltage tolerance -15 %/+20 %
Output of external power supply (DC) 4 W
External unit fuse protection F1 4 A, circuit breaker 24 V DC, characteristic B/C
Status indicator LED
Power dissipation 2,5 W
Inputs
Signal level at "1" 15 - 30 V DC
Input current range 4 mA
Galvanic isolation No
Semiconductor outputs
Overall performance ext. loading, semiconductor 1,2 W
Number 1
Switching current per output 50 mA
Galvanic isolation No
Short circuit-proof yes
Ethernet interface
Number 1
IP address, factory setting 192.168.0.12
Connection type RJ45
Transmission rate 10/100 Mbit/s
Times
Supply interruption before de-energisation 10 ms
Environmental data
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range -30 - 55 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -30 - 70 °C
