Technical details
Operating Manual PITreader, PITreader Firmware V1.5.x
1004806-EN-08
| 52
Environmental data
Climatic suitability
In accordance with the standard EN 60068-2-78
Humidity 93 % r. h. at 40 °C
Max. operating height above sea level 2000 m
EMC EN 301489-1 V2.1.1
Vibration
In accordance with the standard EN 60068-2-6
Frequency 5 - 8,4 Hz, 8,4 - 150 Hz
Amplitude 3,5 mm
Acceleration max. 1g
Shock stress
In accordance with the standard EN 60068-2-27
Acceleration 15g
Duration 11 ms
Protection type
In accordance with the standard EN 60529
Housing IP20
Front IP65/IP67
Mounting area (e.g. control cabinet) ≥ IP54
Mechanical data
Mounting position Any
Material
Bottom PC
Front PC
Connection type Spring-loaded terminal, plug-in
Mounting type plug-in
Max. torque setting for fixing screws 1,3 - 2,1 Nm
Conductor cross section with spring-loaded terminals:
Flexible with/without crimp connector 0,2 - 1,5 mm², 24 - 14 AWG
Spring-loaded terminals: Terminal points per connec-
tion 1
Stripping length with spring-loaded terminals 8 mm
Dimensions
Height 54 mm
Width 72 mm
Depth 45 mm
Weight 47 g
Where standards are undated, the 2018-12 latest editions shall apply.
