Pilz PNOZ m1p User Manual

Commissioning
Operating Manual PNOZ m1p (ETH)
20878-EN-16
24
Input circuit Single-channel Dual-channel
E-STOP
without detection of shorts across
contacts
S1
I0
L+
S1
I1
I0
L+
L+
E-STOP
with detection of shorts across
contacts
I0
T0
S1
S1
T1
I1
T0
I0
Connection examples for the input circuit
Start circuit Input circuit without detection of
shorts across contacts
Input circuit with detection of
shorts across contacts
I5
S3
L+
I5
T0
S3
Connection examples for start circuit
Redundant output
K2
L-
O0 (O2)
O1 (O3)
K1
L-
Single output
K3
L-
K4
O0 (O2)
O1 ( O3)
K1
L-
K2
Connection examples for semiconductor outputs

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
