Technical Details
Operating Manual PNOZ m1p (ETH)
20878-EN-16
31
Inputs 773100 773103 773104 773105
Input current at rated
voltage 8 mA 8 mA 8 mA 8 mA
Min. pulse duration 18 ms 18 ms 18 ms 18 ms
Pulse suppression 0,6 ms 0,6 ms 0,6 ms 0,6 ms
Maximum input
delay 4 ms 4 ms 4 ms 4 ms
Potential isolation No No No No
Semiconductor
outputs
773100 773103 773104 773105
Number 4 4 4 4
Switching capability
Voltage 24 V 24 V 24 V 24 V
Current 2,0 A 2,0 A 2,0 A 2,0 A
Power 48 W 48 W 48 W 48 W
Derating of coated
version at an ambi-
ent temperature >
50 °C
Voltage – – 24 V 24 V
Current – – 1 A 1 A
Power – – 24 W 24 W
Signal level at "1" UB - 0.5 VDC at 2 A UB - 0.5 VDC at 2 A UB - 0.5 VDC at 2 A UB - 0.5 VDC at 2 A
Residual current at
"0" 0,5 mA 0,5 mA 0,5 mA 0,5 mA
Max. capacitive load 1 µF 1 µF 1 µF 1 µF
Max. duration of off
time during self test 300 µs 300 µs 300 µs 300 µs
Switch-off delay 30 ms 30 ms 30 ms 30 ms
Potential isolation yes yes yes yes
Short circuit-proof yes yes yes yes
Semiconductor
outputs (standard)
773100 773103 773104 773105
Number 1 1 1 1
Switching capability
Voltage 24 V 24 V 24 V 24 V
Current 0,50 A 0,50 A 0,50 A 0,50 A
Power 12,0 W 12,0 W 12,0 W 12,0 W
Galvanic isolation yes yes yes yes
Short circuit-proof yes yes yes yes
Residual current at
"0" 0,5 mA 0,5 mA 0,5 mA 0,5 mA
Signal level at "1"
UB - 0.5 VDC at 0.5
A
UB - 0.5 VDC at 0.5
A
UB - 0.5 VDC at 0.5
A
UB - 0.5 VDC at 0.5
A
Test pulse outputs 773100 773103 773104 773105
Number of test pulse
outputs 4 4 4 4

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
