Technical Details
Operating Manual PNOZ m1p (ETH)
20878-EN-16
32
Test pulse outputs 773100 773103 773104 773105
Voltage 24 V 24 V 24 V 24 V
Current 0,5 A 0,5 A 0,5 A 0,5 A
Max. duration of off
time during self test 5 ms 5 ms 5 ms 5 ms
Short circuit-proof yes yes yes yes
Potential isolation No No No No
Relay outputs 773100 773103 773104 773105
Utilisation category
In accordance
with the standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
Utilisation category
of safety contacts
AC1 at 240 V 240 V 240 V 240 V
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
Max. power 1440 VA 1440 VA 1440 VA 1440 VA
DC1 at 24 V 24 V 24 V 24 V
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
Max. power 144 W 144 W 144 W 144 W
Derating of coated
version at an ambi-
ent temperature >
50 °C
Safety contacts,
AC1 at – – 240 V 240 V
Max. current – – 4 A 4 A
Max. power – – 960 W 960 W
Safety contacts,
DC 1 at – – 24 V 24 V
Max. current – – 4 A 4 A
Max. power – – 96 W 96 W
Utilisation category
In accordance
with the standard EN 60947-5-1 EN 60947-5-1 EN 60947-5-1 EN 60947-5-1
Utilisation category
of safety contacts
AC15 at 230 V 230 V 230 V 230 V
Max. current 3,0 A 3,0 A 3,0 A 3,0 A
Max. power 690 W 690 W 690 W 690 W
DC13 (6 cycles/
min) at 24 V 24 V 24 V 24 V
Max. current 3,0 A 3,0 A 3,0 A 3,0 A
Max. power 72 W 72 W 72 W 72 W
Airgap creepage
between
Relay contacts 3 mm 3 mm 3 mm 3 mm
Relay contacts
and other circuits 5,5 mm 5,5 mm 5,5 mm 5,5 mm

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
