Pilz PNOZ m1p User Manual

Technical Details
Operating Manual PNOZ m1p (ETH)
20878-EN-16
33
Relay outputs 773100 773103 773104 773105
External contact
fuse protection,
safety contacts
In accordance
with the standard EN 60947-5-1 EN 60947-5-1 EN 60947-5-1 EN 60947-5-1
Blow-out fuse,
quick 6 A 6 A 6 A 6 A
Blow-out fuse,
slow 6,00 A 6,00 A 6,00 A 6,00 A
Circuit breaker
24V AC/DC, char-
acteristic B/C 6 A 6 A 6 A 6 A
Switch-off delay 50 ms 50 ms 50 ms 50 ms
Potential isolation yes yes yes yes
Cascading output
as standard output
773100 773103 773104 773105
Number 1 1 1 1
Switching capability
Voltage 24 V 24 V 24 V 24 V
Current 0,2 A 0,2 A 0,2 A 0,2 A
Power 4,8 W 4,8 W 4,8 W 4,8 W
Galvanic isolation No No No No
Short circuit-proof yes yes yes yes
Residual current at
"0" 0,5 mA 0,5 mA 0,5 mA 0,5 mA
Ethernet interface 773100 773103 773104 773105
Number
–
2 2
–
Serial interface 773100 773103 773104 773105
Number of RS232
interfaces 1
– –
1
Times 773100 773103 773104 773105
Switch-on delay 5,00 s 5,00 s 5,00 s 5,00 s
Supply interruption
before de-energisa-
tion 20 ms 20 ms 20 ms 20 ms
Simultaneity, chan-
nel 1 and 2 max. 3 s 3 s 3 s 3 s
Simultaneity in the
two-hand circuit 0,5 s 0,5 s 0,5 s 0,5 s
Max. cycle time of
the device 15 ms 15 ms 15 ms 15 ms
Max. processing
time for data com-
munication
–
50 ms 50 ms
–

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
