Pilz PNOZ m1p User Manual

Technical Details
Operating Manual PNOZ m1p (ETH)
20878-EN-16
36
Mechanical data 773100 773103 773104 773105
Conductor cross
section with screw
terminals
1 core flexible
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
2 core with the
same cross sec-
tion, flexible
without crimp
connectors or
with TWIN crimp
connectors
0,25 - 0,75 mm², 24
- 20 AWG
0,25 - 0,75 mm², 24
- 20 AWG
0,25 - 0,75 mm², 24
- 20 AWG
0,25 - 0,75 mm², 24
- 20 AWG
Conductor cross
section with screw
terminals (relay out-
puts)
1 core flexible
0,25 - 2,50 mm², 24
- 12 AWG
0,25 - 2,50 mm², 24
- 12 AWG
0,25 - 2,50 mm², 24
- 12 AWG
0,25 - 2,50 mm², 24
- 12 AWG
2 core with the
same cross sec-
tion, flexible
without crimp
connectors or
with TWIN crimp
connectors
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
Torque setting with
screw terminals 0,25 Nm 0,25 Nm 0,25 Nm 0,25 Nm
Torque setting with
screw terminals (re-
lay outputs) 0,50 Nm 0,50 Nm 0,50 Nm 0,50 Nm
Stripping length with
screw terminals 7 mm 7 mm 7 mm 7 mm
Stripping length with
screw terminals (re-
lay outputs) 8 mm 8 mm 8 mm 8 mm
Conductor cross
section with spring-
loaded terminals
1 core flexible
without crimp
connector
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
0,25 - 1,50 mm², 24
- 16 AWG
1 core flexible
with crimp con-
nector
0,25 - 0,75 mm², 24
- 20 AWG
0,25 - 0,75 mm², 24
- 20 AWG
0,25 - 0,75 mm², 24
- 20 AWG
0,25 - 0,75 mm², 24
- 20 AWG

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
