Technical Details
Operating Manual PNOZ m1p (ETH)
20878-EN-16
35
Environmental data 773100 773103 773104 773105
Airgap creepage
In accordance
with the standard EN 61131-2 EN 61131-2 EN 61131-2 EN 61131-2
Overvoltage cat-
egory III III III III
Pollution degree 2 2 2 2
Rated insulation
voltage 250 V 250 V 250 V 250 V
Rated impulse with-
stand voltage 6,00 kV 6,00 kV 6,00 kV 6,00 kV
Protection type
In accordance
with the standard EN 60529 EN 60529 EN 60529 EN 60529
Mounting area
(e.g. control cab-
inet) IP54 IP54 IP54 IP54
Housing IP20 IP20 IP20 IP20
Terminals IP20 IP20 IP20 IP20
Potential isolation 773100 773103 773104 773105
Potential isolation
between
SC output and sys-
tem voltage
SC output and sys-
tem voltage
SC output and sys-
tem voltage
SC output and sys-
tem voltage
Type of potential
isolation
Protective separa-
tion
Protective separa-
tion
Protective separa-
tion
Protective separa-
tion
Rated surge voltage 2500 V 2500 V 2500 V 2500 V
Potential isolation
between
Relay output and
system voltage
Relay output and
system voltage
Relay output and
system voltage
Relay output and
system voltage
Type of potential
isolation
Protective separa-
tion
Protective separa-
tion
Protective separa-
tion
Protective separa-
tion
Rated surge voltage 6000 V 6000 V 6000 V 6000 V
Mechanical data 773100 773103 773104 773105
Mounting position Horizontal on top
hat rail
Horizontal on top
hat rail
Horizontal on top
hat rail
Horizontal on top
hat rail
DIN rail
Top hat rail 35 x 7,5 EN 50022 35 x 7,5 EN 50022 35 x 7,5 EN 50022 35 x 7,5 EN 50022
Recess width 27 mm 27 mm 27 mm 27 mm
Max. cable length
Max. cable length
per input 1,0 km 1,0 km 1,0 km 1,0 km
Sum of individual
cable lengths at
the test pulse out-
put 40 km 40 km 40 km 40 km
Material
Bottom PPO UL 94 V0 PPO UL 94 V0 PPO UL 94 V0 PPO UL 94 V0
Front ABS UL 94 V0 ABS UL 94 V0 ABS UL 94 V0 ABS UL 94 V0
Connection type Spring-loaded ter-
minal, screw ter-
minal
Spring-loaded ter-
minal, screw ter-
minal
Spring-loaded ter-
minal, screw ter-
minal
Spring-loaded ter-
minal, screw ter-
minal

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
