Pioneer PDP-4270XA User Manual

The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or coloured
red.
NOTE
After replacing or changing a fuse, the fuse cover in the
plug must be replaced with a fuse cover which
corresponds to the colour of the insert in the base of the
plug or the word that is embossed on the base of the plug,
and the appliance must not be used without a fuse cover.
If lost replacement fuse covers can be obtained from your
dealer.
Only 13 A fuses approved by B.S.I or A.S.T.A to B.S.1362
should be used.
P3-4-2-1-2-1_En
The wires in this mains lead are coloured in
accordance with the following code:
Green and Yellow : Earth
Blue : Neutral
Brown : Live
If the plug provided is unsuitable for your socket outlets,
the plug must be cut off and a suitable plug fitted.
IMPORTANT
FOR USE IN THE UNITED
KINGDOM.
The cut-off plug should be disposed of and must not be
inserted into any 13 amp socket as this can result in
electric shock. The plug or adaptor or the distribution
panel should be provided with 13 A fuse. As the colours of
the wires in the mains lead of this appliance may not
correspond with coloured markings identifying the
terminals in your plug, proceed as follows ;
The wire which is coloured green and yellow must be
connected to the terminal in the plug which is marked
with the letter E or by the earth symbol , or coloured
green or green and yellow.
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured
black.
Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified service
personnel.

Pioneer PDP-4270XA Specifications

General

3D	No
Depth	115 mm
Width	1040 mm
Height	679 mm
Weight	31500 g
Tuner type	Analog
Pixel pitch	- mm
Product color	Black, Silver
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	42 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
USB 2.0 ports quantity	0
Annual energy consumption	- kWh
Display diagonal (metric)	106 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	287 W
Digital signal format system	-
Sound enhancement technology	FOCUS, SRS, TruBass
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE
