Pioneer PDP-433CMX Service Manual

100
PDP-433CMX
1234
C
D
F
A
B
E
1
23
4
SIG Mode Signal Type OSD display
V. Frequency
fv (Hz)
H. Frequency
fh (Hz)
Number of Pixels
INPUT5 (DVI input)
Compatibility
00 • 6
00 • 7
00 • 8
00 • 9
SDTV • 625i
(PAL/SECAM)
4 : 3
FULL
ZOOM
WIDE
50 15.6
784 × 768
1024 × 768
1024 × 768
1024 × 768
×
(incompatible)
01 • 6
01 • 7
01 • 8
01 • 9
SDTV • 625p
(PAL • Progressive)
4 : 3
FULL
ZOOM
WIDE
50 31.2
784 × 768
1024 × 768
1024 × 768
1024 × 768
×
(incompatible)
02 • 6
02 • 7
02 • 8
02 • 9
SDTV • 525i
(NTSC/4.43NTSC)
4 : 3
FULL
ZOOM
WIDE
60 15.7
784 × 768
1024 × 768
1024 × 768
1024 × 768
×
(incompatible)
03 • 6
03 • 7
03 • 8
03 • 9
SDTV • 525p
(NTSC • Progressive)
4 : 3
FULL
ZOOM
WIDE
60 31.5
784 × 768
1024 × 768
1024 × 768
1024 × 768
×
(incompatible)
11 • 7
HDTV • 1125 i
(Effective scanning lines: 1080)
FULL
50 28.1
1024 × 768
×
(incompatible)
12 • 7
HDTV • 1125 i
(Effective scanning lines: 1080)
FULL
60 33.8
1024 × 768
×
(incompatible)
13 • 7
HDTV • 1125 i
(Effective scanning lines: 1035)
FULL
60 33.8
1024 × 768
×
(incompatible)
14 • 7
HDTV • 750p
(Effective scanning lines: 720)
FULL
60 45.0
1024 × 768
×
(incompatible)
15 • 7
HDTV • 1125 p
(Effective scanning lines: 1080)
FULL
60 67.5
1024 × 768
×
(incompatible)
Classification 1 of Input Signal Mode (VIDEO)
• When this mode is entered, the MASK OFF display (the function called by pressing the "1" key) is displayed first. However, if any MASK
setting has been already made, the selected MASK item is displayed first.
• If this mode is entered with any of the MASK items in MASK 1 selected, the settings for MASK 1 become invalid, and the MASK OFF
display (the function called by pressing the "1" key) is displayed first.
• When any of the above keys is pressed, the current adjustment value is stored in memory, then the corresponding operation will be
executed.
Note: During MASK setting, an OSD is not displayed. If another operation is selected, an OSD is displayed for 2 seconds after the MASK
signal output is stopped, then the selected MASK display will be displayed again.
Operating specifications
