Pioneer PDP-433CMX Service Manual

99
PDP-433CMX
5
678
5
6
7
8
C
D
F
A
B
E
MASK2
2
Rem Code Key Name Function & Display Description Remarks
Lower
Layer
AA01 1 MASK OFF OFF ×
AA02 2 MASK 01 Pattern 1 (Ramp) ×
AA03 3 MASK 02 Pattern 2 (Color-bars) ×
AA04 4 MASK 03 Pattern 3 (Slanting lines) ×
AA05 5 MASK 04 Pattern 4 (For W/B Lo-Light adjustment
1/5Window (14%, 56%))
×
AA06 6 MASK 05 Pattern 5 (For W/B Lo-Light adjustment
1/5Window (Pred, Skin))
×
AA07 7 MASK 06 Pattern 6 (For W/B Peak adjustment
1/5Window (100%))
×
AA08 8 MASK 07
Pattern 7 (Peak signal : For peak measurement
and adjustment 1/5Window (100%))
×
AA09 9 MASK 08 Pattern 8 (Reservation) ×
AA00 10 MASK 09
Pattern 9 (Window-A for scan IC protection test) ×
AA46 11 MASK 10
Pattern 10 (Window-B for scan IC protection test) ×
AA47 12 MASK 11 Pattern 11 (Reservation) ×
AA4D BS1 MASK 12 Pattern 12 (Reservation) ×
AA4E BS3 MASK 13 Pattern 13 (Reservation) ×
AA4F BS5 MASK 14 Pattern 14 (Reservation) ×
AA50 BS7
AA51 BS9
AA52 BS11
AA53 BS13
AA54 BS15
AA96 5
Selection of upper items
AA97 ∞ Selection of lower items
AA94
Selection of free-running frequency ••→50Hz→60Hz→70Hz→•• Default: 60 Hz
AA95
Selection of free-running frequency ••→50Hz→60Hz→70Hz→•• Default: 60 Hz
AA8A SET
Storing data of the selected item and shifting to upper layer
AAD3-AF70
AA4A
AUDIO
DISPLAY CALL
Shifting to various adjustment /
setting screen
INFORMATION
AA1D
SURROUND MODE RANGE CHECK
AA59
AA43
AV SELECT
AV MEMORY
REFERENCE
AA1E MPX OFFSET
AAD3-AF3C SCREEN SIZE VIDEO OPTION
AAD3-AF36
AAD3-AF22
FULL AUTO ZOOM
P.ZOOM
INITIALIZE
AA49 MUTING
Shifting to next adjustment / setting screen INFORMATION
Display color : White
Half tone : Blue (second line / 15th line for
each 1st to 32th columns)
Perform the adjustment of each parameter.
Basic Operation
––S
MASK : OFF
1IN4– 02– ∗2NT#1
INI T– MASK
(
60Hz
)
2
1
5
10
15
16
1 5 10 15 20 25 30 32
