98
PDP-433CMX
1234
C
D
F
A
B
E
1
23
4
MASK1
1
Display color : White
Half tone : Blue (second line / 15th line for
each 1st to 32th columns)
Perform the adjustment of each parameter.
Basic Operation
• When this mode is entered, the MASK OFF display (the function called by pressing the "1" key) is displayed first. However, if any MASK
setting has been already made, the selected MASK item is displayed first.
• If this mode is entered with any of the MASK items in MASK 2 selected, the settings for MASK 2 become invalid, and the MASK OFF
display (the function called by pressing the "1" key) is displayed first.
• To select the MASK67 to MASK74, press the 5 (UP) or ∞ (DOWN) key.
•
When any of the above keys is pressed, the current adjustment value is stored in memory, then the corresponding operation will be executed.
Note: During MASK setting, an OSD is not displayed. If another operation is selected, an OSD is displayed for 2 seconds after the MASK
signal output is stopped, then the selected FULL MASK display will be displayed again.
Operating specifications
INI T –––SMASK
MASK : OFF
(
60Hz
)
11IN4– 02– ∗2NT#1
1
5
10
15
16
1 5 10 15 20 25 30 32
Rem Code Key Name Function & Display Description Remarks
Lower
Layer
AA01
1 OFF OFF ×
AA02
2 MASK51 White
×
AA03
3 MASK52 Cyan 274
×
AA04
4 MASK53 Mazenta 1023 ×
AA05
5 MASK54 Flesh color ×
AA06
6 MASK55 Cyan 1023 ×
AA07
7 MASK56 Light purple ×
AA08
8 MASK57 Sky blue ×
AA09
9 MASK58 Red ×
AA00
10 MASK59 Green ×
AA46
11 MASK60 Blue ×
AA47
12 MASK61 Black ×
AA4D
BS1 MASK62 Red 779 ×
AA4E
BS3 MASK63 Cyan 218 ×
AA4F
BS5 MASK64 Cyan 444 ×
AA50
BS7 MASK65 Flesh color 43 ×
AA51
BS9 MASK66
MASK67
MASK68
MASK69
MASK70
Red 620
Full mask (Mazenta 98)
Full mask (Sky blue 1_43)
Full mask (Sky blue 2_43)
Full mask (Light purple 43)
×
×
×
×
×
MASK71
MASK72
MASK73
MASK74
Full mask (Yellow)
Full mask (Blue 916)
Full mask (Reserved)
Full mask (Reserved)
×
×
×
×
AA52
BS11
AA53
BS13
AA54
BS15
AA96 5
Selection of upper items
AA97 ∞ Selection of lower items
AA94
Selection of free-running frequency
••→50Hz→60Hz→70Hz→••
Default: 60 Hz
AA95
Selection of free-running frequency
••→50Hz→60Hz→70Hz→••
Default: 60 Hz
AA8A SET
Storing data of the selected item and shifting to upper layer
AAD3-AF70
AA4A
AUDIO
DISPLAY CALL
Shifting to various adjustment /
setting screen
INFORMATION
AA1D SURROUND MODE RANGE CHECK
AA59
AA43
AV SELECT
AV MEMORY
REFERENCE
AA1E MPX OFFSET
AAD3-AF3C SCREEN SIZE VIDEO OPTION
AAD3-AF36
AAD3-AF22
FULL AUTO ZOOM
P.ZOOM
INITIALIZE
AA49 MUTING
Shifting to next adjustment / setting screen
INFORMATION
To Next Page
