6.3.2 MAIN UNIT ADJUSTMENT
VIDEO OPTION mode in
Factory mode
SIDE MASK LEV.
R SIDE LEVEL : key 1
G SIDE LEVEL : key 2
B SIDE LEVEL : key 3
Side mask color / Level Adjustment
Set the indicated value with the keys on the remote control unit (1, 2 and 3 keys).
Input Signal
Adjusting Point Adjusting Method
Input Signal
Adjusting Point Adjusting Method
Reference : Adjustment values when using the Minolta color-difference meter (A-100)
Adjust the OFFSET-DIGITAL parameters (from PANEL R-HIGH to PANEL B-LOW) in Factory
mode.
For adjustment, use the mask (MASK04) signal of Factory mode for display.
Panel-White-Balance Adjustment
Mask-Level Adjustment
MASK Left Side
x293
y308
MASK Right Side
292
296
