Command Name Function
RS-232C
Factory
RS-232C
Integrator
Normal
Validity
Direct
Validity
UP/DOWN
Validity
G
GWB GET WHITE BALANCE TxD outputs of data of picture quality setting of RGB1 O O O −−
GPD GET POWER DOWN TxD outputs of POWER DOWN information O −−− −
H
HCN HIGH CONTRAST NO To turn the high contrast setting to OFF O O −− −
HCY HIGH CONTRAST YES To turn the high contrast setting to ON O O −− −
HMS HOUR METER SET To set the hour meter to optional time O −−O −
HMD HOUR METER DISP. To display the hour meter O O −− −
H80 HDTV MODE 1080 i To set the HDTV mode to 1080 i O O −− −
H35 HDTV MODE 1035 i To set the HDTV mode to 1035 i O O −− −
I
IN1 INPUT1 To select INPUT1 O O O −−
IN2 INPUT2 To select INPUT2 O O O −−
IN3 INPUT3 To select INPUT3 O O O −−
IN4 INPUT4 To select INPUT4 O O O −−
IN5 INPUT5 To select INPUT5 O O O −−
IMN INTEGRATOR MODE NO To set the Integrator mode to LOCK O −−− −
IMY INTEGRATOR MODE YES To set the Integrator mode to UNLOCK O −−− −
IDC ID CLEAR To clear the ID O O −− −
IDS ID SET To set the ID O O − O −
K
KLN KEY LOCK NO To permit main unit key / remote control unit operation O O −− −
KLY KEY LOCK YES To prohibit main unit key / remote control unit operation O O −− −
M
M00 MASK 00 Mask mode OFF O −−− −
M01 MASK 01 Pattern 1 (ramp) O −−− −
M02 MASK 02 Pattern 2 (color bars) O −−− −
M03 MASK 03 Pattern 3 (slanting lines) O −−− −
M04 MASK 04 Pattern 4 (for W/B measurement) O −−− −
M05 MASK 05 Pattern 5 (for W/B adjustment) O −−− −
M06 MASK 06 Pattern 6 (for W/B peak measurement) O −−− −
M07 MASK 07 Pattern 7 (for peak measurement) O −−− −
M08 MASK 08 Pattern 8 (reservation) O −−− −
M09 MASK 09 Pattern 9 (for SCAN IC protection test) O −−− −
M10 MASK 10 Pattern 10 (for SCAN IC protection test) O −−− −
M11 MASK 11 Pattern 11 (reservation) O −−− −
M12 MASK 12 Pattern 12 (reservation) O −−− −
M13 MASK 13 Pattern 13 (reservation) O −−− −
M14 MASK 14 Pattern 14 (reservation) O −−− −
M51 MASK 51 Full mask (white) O −−− −
M52 MASK 52 Full mask (cyan 274) O −−− −
M53 MASK 53 Full mask (mazenta 135) O −−− −
M54 MASK 54 Full mask (flesh color) O −−− −
M55 MASK 55 Full mask (cyan 1023) O −−− −
M56 MASK 56 Full mask (light purple 5) O −−− −
M57 MASK 57 Full mask (sky blue) O −−− −
M58 MASK 58 Full mask (red) O −−− −
M59 MASK 59 Full mask (green) O −−− −
M60 MASK 60 Full mask (blue) O −−− −
M61 MASK 61 Full mask (black) O −−− −
M62 MASK 62 Full mask (reservation) O −−− −
M63 MASK 63 Full mask (reservation) O −−− −
M64 MASK 64 Full mask (reservation) O −−− −
M65 MASK 65 Full mask (reservation) O −−− −
M66 MASK 66 Full mask (reservation) O −−− −
MG1 2X2MODE LEFT UPPER Four enlarged setting: Upper left O O −− −
MG2 2X2MODE LEFT LOWER Four enlarged setting: Lower left O O −− −
MG3 2X2MODE RIGHT UPPER Four enlarged setting: Upper right O O −− −
MG4 2X2MODE RIGHT LOWER Four enlarged setting: Lower right O O −− −
MGY 2X2MODE YES To turn the four sides multi to ON O O O −−
MGN 2X2MODE NO To turn the four sides multi to OFF O O O −−
MMN MIRROR MODE NO To turn the mirror mode to OFF (normal display) O O O −−
MMX MIRROR MODE X Right and left reversing display O O O −−
MMY MIRROR MODE Y Top and bottom reversing display O O O −−
MMZ MIRROR MODE XY Top/bottom and right/left reversing display O O O −−
MTN VIDEO MUTE NO To turn the video mute of IC30 to OFF O O O −−
MTY VIDEO MUTE YES To turn the video mute of IC30 to ON O O O −−
