Command Function
GAJ Outputting data for electronic-control-adjustment values and drive-system-adjustment values
GPW Outputting data related to the white-balance adjustment for the panel
GS1 Outputting data such as version information, and data from the hour meter and pulse meter
GS2 Outputting data for power down, temperature and condensation information
GAS Outputting data related to the picture quality setting of SLOT
GAR Outputting data related to the picture quality (RGB1 of the Factory menu)
GPS Outputting data related to SCREEN adjustment data
GPD Outputting data on PD information of Service Factory menu (past eight times)
GWB Outputting data related to picture quality / white balance
GSD Outputting TxD data on SD information of Service Factory menu
GSS Outputting data on SETUP items of menu mode / Integrator menu
GSO Outputting data on OPTION items of menu mode / Integrator menu
Order Data Contents Size Remarks
1 Setting mode of electric power upper limit value 3 byte AB* ( *: 0 to 3)
2
Electric power upper limit value
(ABL)
(Reference data) 3 byte
3 (Offset data) 3 byte (Note 1)
4 Vsus adjustment value (Reference data) 3 byte
5 Vofs adjustment value (Reference data) 3 byte
6 V-SUS-B adjustment value (Reference data) 3 byte
7 V-SUS-G adjustment value (Reference data) 3 byte
8 Y-SUS-B adjustment value (Reference data) 3 byte
9 Y-SUS-G adjustment value (Reference data) 3 byte
Order Data Contents Size Remarks
1 Panel color temperature mode 3 byte PT* ( *: 0 to 3)
2
Gain of W/B adjustment value
Red
(Reference data) 3 byte
3 (Offset data) 3 byte (Note 1)
4
Gain of W/B adjustment value
Green
(Reference data) 3 byte
5 (Offset data) 3 byte (Note 1)
6
Gain of W/B adjustment value
Blue
(Reference data) 3 byte
7 (Offset data) 3 byte (Note 1)
8
Offset of W/B adjustment value
Red
(Reference data) 3 byte
9 (Offset data) 3 byte (Note 1)
10
Offset of W/B adjustment value
Green
(Reference data) 3 byte
11 (Offset data) 3 byte (Note 1)
12
Offset of W/B adjustment value
Blue
(Reference data) 3 byte
13 (Offset data) 3 byte (Note 1)
GAJ:
Outputting data for electronic-control-adjustment values and drive-system-adjustment values
• Data are output according to the transmission order and size of the table below.
• This command is invalid in modes other than RS-232C Factory Adjustment mode.
GPW
(Get Panel White balance)
:
Outputting data related to the white-balance adjustment for the panel
• Data are output according to the transmission order and size of the table below.
• This command is invalid in modes other than the RS-232C Factory Adjustment mode.
(Note 1) : If data are output when the Reference mode is selected, the same data as the reference data are output as the offset data.
(Note 1) : If data are output when the Reference mode is selected, the same data as the reference data are output as the offset data.
