GPD (Get Power Down), PD (Power Down) : Outputting data on PD INFORMATION of the Service
Factory MENU
• The acquired data are output according to the transmission order and size in the table below.
• This command is valid only in RS-232C Factory Adjustment mode and during power-down.
Note: During power-down, data can be obtained by directly executing "GPD" without executing "FAY." However, the ID must be set
beforehand.
Order Data Contents Size Remarks
1 The latest "1stPD INFO" 1 byte (Note 1)
2 The latest "2ndPD INFO" 1 byte (Note 1)
3 Hour meter information of the latest PD 7 byte Upper 5byte: HOUR, Lower 2byte: MINUTE
4 Second latest "1st PD INFO" 1 byte (Note 1)
5 Second latest "2nd PD INFO" 1 byte (Note 1)
6 Hour meter information of the second latest PD 7 byte Upper 5byte: HOUR, Lower 2byte: MINUTE
7 Third latest "1st PD INFO" 1 byte (Note 1)
8 Third latest "2nd PD INFO" 1 byte (Note 1)
9 Hour meter information of the third latest PD 7 byte Upper 5byte: HOUR, Lower 2byte: MINUTE
10 Fourth latest "1st PD INFO" 1 byte (Note 1)
11 Fourth latest "2nd PD INFO" 1 byte (Note 1)
12 Hour meter information of the fourth latest PD 7 byte Upper 5byte: HOUR, Lower 2byte: MINUTE
13 Fifth latest "1st PD INFO" 1 byte (Note 1)
14 Fifth latest "2nd PD INFO" 1 byte (Note 1)
15 Hour meter information of the fifth latest PD 7 byte Upper 5byte: HOUR, Lower 2byte: MINUTE
16 Sixth latest "1st PD INFO" 1 byte (Note 1)
17 Sixth latest "2nd PD INFO" 1 byte (Note 1)
18 Hour meter information of the sixth latest PD 7 byte Upper 5byte: HOUR, Lower 2byte: MINUTE
19 Seventh latest "1st PD INFO" 1 byte (Note 1)
20 Seventh latest "2nd PD INFO" 1 byte (Note 1)
21 Hour meter information of the seventh latest PD 7 byte Upper 5byte: HOUR, Lower 2byte: MINUTE
22 Eighth latest "1st PD INFO" 1 byte (Note 1)
23 Eighth latest "2nd PD INFO" 1 byte (Note 1)
24 Hour meter information of the eighth latest PD 7 byte Upper 5byte: HOUR, Lower 2byte: MINUTE
Data Power Down Point
0 None
1 Y-DRIVE
2 Y-DC/DC CONVERTER
3 X-DC/DC CONVERTER
4 X-DRIVE
5 Power supply
6 ADDRESS junction
7 ADDRESS resonance
8 DC/DC CONVERTER (DIGITAL)
(Note 1) See the table below on PD information
