GSD
(Get Shut Down)
:O
utputting TxD data on SD (Shut Down) INFORMATION of
Service Factory MENU
• The acquired data are output according to the transmission order and size in the table below.
• This command is valid only in RS-232C Factory Adjustment mode and during shut down (for 30 seconds until a shutdown occurs or standby).
Note: During power-down, data can be obtained by directly executing "GPD" without executing "FAY." However, the ID must be set
beforehand.
Order Data Contents Size Remarks
1 The latest "SD INFO" 1 byte (Note 1)
2 First latest "SD INFO" 1 byte (Note 1)
3 Second latest "SD INFO" 1 byte (Note 1)
4 Third latest "SD INFO" 1 byte (Note 1)
5 Fourth latest "SD INFO" 1 byte (Note 1)
6 Fifth latest "SD INFO" 1 byte (Note 1)
7 Sixth latest "SD INFO" 1 byte (Note 1)
8 Seventh latest "SD INFO" 1 byte (Note 1)
GET Data Shut Down Point
1 Panel microcomputer communication failure
2 Module IIC communication failure
3 Condensation
4 Temperature abnormality
5 FAN abnormality
6 Module microcomputer communication failure
7 Wide microcomputer communication failure
8 Main IIC communication failure
9 AUDIO failure
(Note 1) See the table below on SD information
Table 1: GSD
Table 2: SD contents
