GSO:
Outputting data on
OPTION items of the menu mode / Integrator menu
• Data are output according to the transmission order and size in the table below.
• This command is valid only in Normal Operation mode, RS-232C Integrator Adjustment mode, and RS-232C Factory adjustment mode.
(Note 1) Dummy data (*) are output when a SLOT manufactured by Pioneer is connected.
Order Data Contents Size Output Remarks
1 POWER CONTROL 3 byte Same as the RS-232C command
2 OSD display 1 byte
0: OSD display prohibition
1: OSD display permission
3 FULL MASK 3 byte
Display a RS-232C command
of currently set MASK
4 R SIDE MASK LEVEL 3 byte Adjustment value
5 G SIDE MASK LEVEL 3 byte Adjustment value
6 B SIDE MASK LEVEL 3 byte Adjustment value
7 MASK CONTROL 1 byte 0: OFF, 1: ON
8 ORBITER MODE 1 byte 0: OFF, 1: ON
9 INVERSE MODE 1 byte 0: OFF, 1: ON
10 COLOR MODE 1 byte
1: COLOR MODE1
2: COLOR MODE2
11 MIRROR MODE 1 byte
X: Right and left inverting
Y: Top and bottom inverting
Z: Top/bottom and right/left inverting
N: OFF
12 FAN CONTROL 1 byte
A: AUTO
M: MAX
13 MONITOR NAME 12 byte
14 SLOT INPUT 1 byte
0: VIDEO (RGB)
1: COMPONENT1
2: COMPONENT2
(Note 1)
15 TEMPERATURE 3 byte A/D input value (Note 2)
16 HOUR METER 5 byte Unit : H
17 KEY LOCK 1 byte
0: Lock release
1: Lock
