The PD history displayed in "INFORMATION" of the Factory menu.
Display of PD point
Time stamp display
[OOOOOH] : HOUR, [OOM] : MINUTE
Example:
Time stamp display is [65432H10M] → 65432 hours 10 minutes
Time stamp data
upper 5 byte: HOUR, lower 2 byte: MINUTE
Example:
Time stamp is [6543210] → 65432 hours 10 minutes
The data (1st/2nd/time stamp) on the past eight power-downs are stored in memory.
Diagnosis Method in Power Down
1 OSD display of the PD history
2 Retrieval of PD history by RS-232C command "GPD"
Power-Down Point OSD Display
Y-DRIVE Y-DRV
Y-DC/DC COVERTER Y-DDC
X-DC/DC CONVERTER X-DDC
X-DRIVE X-DRV
Power supply POWER
ADDRESS junction ADRES
ADDRESS resonance ADR-K
DC/DC CONVERTER (DIGITAL) DC-DC
Data of PD point
Power-Down Point "GPD" Data
Y-DRIVE 1
Y-DC/DC COVERTER 2
X-DC/DC CONVERTER 3
X-DRIVE 4
Power supply 5
ADDRESS junction 6
ADDRESS resonance 7
DC/DC CONVERTER (DIGITAL) 8
Order Data contents Size
1 The latest "1st PD" point 1 byte
2 The latest "2nd PD" point 1 byte
3 The latest PD time stamp 7 byte
4 Second latest "1st PD" point 1 byte
5 Second latest "2nd PD" point 1 byte
6 Second latest PD time stamp 7 byte
7 Third latest "1st PD" point 1 byte
8 Third latest "2nd PD" point 1 byte
9 Third latest PD time stamp 7 byte
10 Fourth latest "1st PD" point 1 byte
11 Fourth latest "2nd PD" point 1 byte
12 Fourth latest PD time stamp 7 byte
13 Fifth latest "1st PD" point 1 byte
14 Fifth latest "2nd PD" point 1 byte
15 Fifth latest PD time stamp 7 byte
16 Sixth latest "1st PD" point 1 byte
17 Sixth latest "2nd PD" point 1 byte
18 Sixth latest PD time stamp 7 byte
19 Seventh latest "1st PD" point 1 byte
20 Seventh latest "2nd PD" point 1 byte
21 Seventh latest PD time stamp 7 byte
22 Eighth latest "1st PD" point 1 byte
23 Eighth latest "2nd PD" point 1 byte
24 Eighth latest PD time stamp 7 byte
IN
PD
F
1 X DDC 05148H25M
02248H14M
01358H36M
00348H15
00000 00
00000 00
00000 00
00000 00
M
2ADR– K
3YDRV
4
–
X – DDC
D – DCC
ADRES
–
5 –––––
–––––
–––––
–––––
6
7
8
H
H
H
H
M
M
M
M
–––––
–––––
–––––
–––––
–––––
–––––
O
INFO
1ST 2ND
––S1 I N4– 02– ∗2NT#1
1
1
5
10
15
16
5 101520253032
