Pioneer PDP-433CMX Service Manual

139
PDP-433CMX
5
678
5
6
7
8
C
D
F
A
B
E
1
Remove the three screws.
2
2
Loosen the rivet.
3
3
Remove the lead cover MX.
Turn the rivet, taking care not to push
on it, because pushing on it may set
the rivet to its original position.
Remove the lead cover MX together
with the rivet when the rivet is fully
loosened.
Rivet
4
Pull out the flexible cable.
5
5
Detach the lower part of the front case assy 43 (M) so that it
can swing open hinged at the top.
6
6
Remove the front case assy 43 (M).
×3
7
Remove the rear case (M). (Screws × 20)
9
Remove the front chassis V. (Screws × 5)
Remove the scan IC spring (43L, 43R). (Screw × 1)
8
Remove the Y DRIVE Assy.
(Connector, PCB spacers × 3, screws × 8)
Reverse the SCAN (A) and SCAN (B) assemblies.
12
11
10
Exchange the ROM if necessary.
Y DRIVE, SCAN (A), (B) Assy
1
Front Case Assy 43 (M)
Front Case Assy 43 (M)
Aluminum
Materials
The hook of the front case assy 43 (M)
is fixed with the rear case (M) and
the aluminum material, as shown in
the illustration.
Rear Case
(M)
Lead Cover MX
Lead Cover
MX
SIDE KEY
Assy
44
×2
8
×2
8
8
Y DRIVE Assy
Scan IC Spring
(43R)
Front Chassis V
Scan IC Spring
(43L)
9
9
9
10
9
×2
8
×2
8
9
SCAN (A) Assy
ROM
×6
ROM ×6
SCAN (B) Assy
11
11
